Engine

Model

Perkins 1104D-44T

Type

Four-Stroke, Turbo Boost

Number of Cylinder

4

Cylinder Diameter/Travel

105*127mm

Displacemint

4.4L

Power(KW/hp)

74.5/101.32

Rated Speed(rpm)

2200

Max. Torque(NM)

400NM/1400rpm

Emission standard

Stage III A/ Tier3

Fan Specification

6 Vane Induced-draught

Diameter

540mm

Speed Ratio

1.25:1

Running Speed(km/h)

Forward (I, II, III, IV)

5.8, 10.5, 20.1, 40.2

Reverse (I, II, III, IV)

5.8, 10.5, 20.1, 40.2

Work Performance (Loading End)

Loading Movable Boom Breakout Force

55KN

Loading Bucket Breakout Force

68KN

Lifting Load at Max. Height

3600kg

Ground Bucket Retracting Angle

47°

Max. Height of Dump

2.79m

Max. Distance of Dump

0.72m

Dump Angle

45°

Utility Loading Bucket Volume

1.0m3

Four in One Loaded Bucket Volume

1.0m3

Work Performance (Mining End)

Digging Force of Bucket Cylinder

67KN

Digging Force of Arm Cylinder

45KN

Turning Angle

L/R 180°

Max. Dump Height

Distance of Leg Out 4.03m

Max. Digging Distance(extended)

5.32m (6.47m)

Max. Lateral Distance of Digging Device

1.0m

Backhoe Bucket Volume

0.25m3/0.43m3
